Alpine R-A60F

Small foot print, high output Clean class D – Small, clean and powerful amplifier. Also has built in adjustment to use it in active set-ups with bandpass functionality, accepts a "bass knob" but Alpine makes you buy it separately for around $70.00. The supplied "feet" are terrible quality and the amp housing is not like days of old where everything was heavy heat sinks and solid plastics - it works but doesn't look or feel premium.

Good screw down grub terminals compatible with ferrules but unfortunately pointed down requiring the amp be fitted on risers to allow cables to clear the mounting surface.

Overall happy with the amp size and output, cant complain too much about the average housing quality because the price of the amplifier is really quite reasonable for the output and brand.

Features All-new Advanced Digital Design Compact Chassis Easy Access Controls RCA and Speaker Level Inputs Bandpass Filter Superior Sound Stage Bridgeable Bass EQ Variable High Pass/Low Pass Filters Thermal Protection Rotatable Alpine Badge Remote Bass Knob Ready (RUX-KNOB.2) Hi-Res Audio Certified Specifications Output

Output Channels: 4 Channels RMS Power Ratings

Power (@14.4V 1% THD) Per Channel into 4 Ohms: 100W X 4 Per Channel into 2 Ohms: 150W X 4 Bridged 4 Ohms: 300W X 2 [4Ω@14.4V] Max Power Output: 1200W Frequency Response

Frequency Response: 10Hz-45kHz (+/-3dB) Damping Factor

Damping Factor: 500> Dimensions

Heat Sink (WxHxD): 273 x 50.8 x 200mm With attached brackets: 273 x 50.8 x 223mm
